10.1 Inch 1920x1080 AHD TFT Car Monitor Waterproof HD Rear View System
SPECIFICATION
7"/9"/10.1"4CH AHD Monitor Built-in DVR(The Hayes Plan)
Resolution:1024*R.G.B*600 Back Light Luminance:LED,LED,500-650cd/㎡
View angle: L/R:85°,UP:85°,down:85° degree
Video input:4 channels of AHD1080P/960P/720P and 960H,
D1 (CVBS) and other video input;
6-channel / 8-channel split (optional)
Compatible with mixed input of CVBS signals and AHD signals
Compatible with mixed input of PAL and NTSC
Trigger input:3-8 set I/O trigger, support 12-24V power triggered full-screen indication (optional)
Preview function:Previewing of spliced 12 multi-screen modes, supporting manual/voltage triggered full-screen display function
Built DVR function( 4 channel video recording)
Video resolution:1920*1080
Video compression format:H.264 compression mode
Video image quality:4 levels adjustable: super - clear, HD, standard, common video
Audio input:Support 1 channel audio input (CH1 interface) (Customization optional)
Compression input :G.726 compression format
SD card:Support 2-512G storage card, full disc automatic deleting, cyclic coverage(for Monitor with DVR type)
Playback :Synchronous playback of 4 channels, support pause, fast forward, fast back
Power management:Self-adaptive wide-range power input, with under - voltage protection, over - voltage protection, reverse short-circuit protection and other protections;
Input voltage:DC + 12-36V (For operation with a camera, the required input voltage is 13V and above)
Output voltage:+11.5V/3A
Power consumption:Normal operation status ＜ 5W (not including the display screen and the camera)
Temperature:-20℃ to +70℃
ppearance color: black rubber paint
Butterfly bracket/fan bracket/Suction Cup holder (optional)
RCA/ 4pin connector (Optional)
PRODUCT PHOTO
CABLE SPECIFICATION
INSTALLATION
